Material:

• Carbon Steel (Grade 2, 4.6, A307) or Stainless Steel (SS304, SS316)
• Available with Zinc Plating, Hot-Dip Galvanized (HDG), or Black Oxide coatings for corrosion resistance.

Thread Specifications:

• Thread Size: 7/16 inch (11.11mm)
• Thread Pitch: 14 threads per inch (TPI) (Unified Coarse Thread – UNC)
• Thread Standard: ANSI/ASME B1.1

Bolt Dimensions & Features:

• Head Type: Hexagonal (Breakaway Design)
• Wrench Size: 5/8 inch (for hex head before breakaway)
• Bolt Lengths Available: 4 inches, 7 inches (custom lengths on request)
• Breakaway Torque: Pre-calibrated to shear off at a specific torque value, ensuring uniform clamping force.
• Tensile Strength:
  • Carbon Steel: 60,000 – 100,000 psi (depending on grade)
  • Stainless Steel: 80,000 – 125,000 psi

Applications:

• Used in structural connections, mechanical fastenings, and anti-tamper security applications.
• Common in bridges, railways, high-speed trains, and heavy-duty construction.
• Ensures controlled clamping force and prevents over-tightening.
• Used in electrical enclosures, safety barriers, and infrastructure security.

Additional Features:

• Breakaway Head Design: Prevents unauthorized removal once installed.
• Corrosion-Resistant Coating: Suitable for harsh outdoor environments.

Precision Engineering: Ensures high-strength, tamper-proof connections.
